Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Effective Pixels: 1920(H)x1080(V)
Signal System: PAL/NTSC
Minimum Illumination: Color: 0.05 Lux @ (F2.0, AGC ON), B/W: 0.005Lux @ (F2.0, AGC ON)
White Balance: Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp
AGC: Auto/Manual
HLC: Support
WDR: DWDR
Shutter Time: 1/1 to 1/10,000s
Day& Night: ICR
Digital Zoom: 16×
Privacy Masking: 8 privacy masks programmable
Auto Focus: Auto / Semi-automatic / Manual
Lens
Focal Length: 2.8 to 12mm, 4×
Zoom Speed: Approx. 2s (optical lens, wide-tele)
Angle of View: 100° to 25° (wide-tele)
Minimum Working Distance: 10 to 1500mm (wide-tele)
Aperture Range: F1.8 to F2.5
Pan & Tilt
Pan Range: Pan: 0~350°
Pan Speed: 0.1° to 60°/s
Tilt Range: Tilt: 0°~90°
Tilt Speed: 0.1°to 50°/s
Proportional Zoom: Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset: 300
Patrol: 8 patrols, up to 32 presets per patrol
Power-off Memory: Support
Park Action: Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
PTZ Position Display: ON/OFF
Infrared
IR irradiation distance: 20m
IR irradiation angle: Adjustable by zoom
Alarm
Alarm Input: 1
Alarm Actions: Preset, Patrol, Pattern, Recording, Relay output, Upload center, upload FTP, email linkage
Input & Output
Audio Input: Audio input (LINE input), 2-2.4Vp-p; output impedance: 1KΩ, ±10%
Audio Output: 1 channel audio output, linear level
Network
Ethernet: 10Base -T, /100Base-TX, RJ45 Connector
Max.Image Resolution: 1920×1080
Main Stream: 50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps (1280×720)
60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps (1280×720)
Sub Stream: 50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240)
Third Stream: 50Hz:25fps(1280×960), 25fps (1280×720), 25fps(704×576), 25fps (352×288), 25fps (176×144)
60Hz:30fps(1280×960), 30fps (1280×720), 30fps(704×480), 30fps (352×240), 30fps (176×120)
Video Compression: H.264 / MJPEG
Audio Compression: G.711ulaw/G.711alaw/G.726/MP2L2/G.722
Audio Mode: OFF/Audio input/Audio output
General
Power Supply: 12V DC & PoE((802.3af, class3)
Power Consumption: Max.: 9W
Working Temperature/Humidity: -10°C to 50°C (-14°F to 122°F)
Protection Level: TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
Weight (approx.): Approx. 0.65kg (1.4lb)
